ENERDRIVE EPOWER 1000W/12V PSW Inverter
Description
With ePOWER’s state of the art, easy to use design, this 1000W inverter will offer you reliable service for providing AC power and 5V USB power for your home, boat, caravan, 4WD or commercial vehicle.
The Enerdrive ePOWER 1000W Inverter can run many AC powered appliances when you need AC power anywhere. The 5V USB power can charge many USB powered devices.
FEATURES
Australian GPO Outlets
True sine wave output is ideal for operating motor loads, and to reduce stress on surge protection circuitry, meaning potentially longer equipment life
Audio alarm with warning/error codes to alert user to check inverter condition before unit shutdown
Automatic shutdown protects overload, over temperature and low/high battery conditions
High surge capacity for products that require more power to start (2 x constant)
High efficiency conversion of battery available power to AC power
Mounting brackets for permanent installation
Heavy duty DC battery stud connectors
Includes 5V USB port
6 Meter Remote On / Off Switch Included with both 1000W and 2000W Inverter Models
SPECIFICATIONS
Model Description
ePOWER 1000
Part Number
EN1110S
AC Output Power
1000W
AC Output Current
4.3A
AC Surge Power (Peak)
900W
AC Output Voltage
230 Vac / 50 Hz
AC Output Waveform
True Sinewave
AC Output Socket
1 outlet
Nominal DC Input Voltage
12.5 VDC
No Load battery draw
1.2 ADC
DC Input Voltage operating range
10.5 15.5 VDC
Under Voltage Alarm
11.2 VDC
Under Voltage Shutdown
10.5 VDC
Under Voltage Recovery
11.8 VDC
Over Voltage Shutdown
15.5 VDC
USB
5V, 2.1A
Safety and Environmental
Conformance
All required Australian Standards
Agency Markings
RCM
Operating Temperature
0C to 40C
Storage Temperature
-20C to 60C
Relative Humidity
5-90% noncondensing
Weights and Dimensions
Weight
2.9Kg
Dimensions (W x L x H)
177 x 325 x 90mm
Warranty
5 Years
PACKAGE INCLUDES
1 x Pure Sine Power Inverter
WARRANTY
5 Years Warranty
Specifications
Model – Description | ePOWER 1000 |
Part Number | EN1110S |
AC Output Power | 1000W |
AC Output Current | 4.3A |
AC Surge Power (Peak) | 900W |
AC Output Voltage | 230 Vac / 50 Hz |
AC Output Waveform | True Sinewave |
AC Output Socket | 1 outlet |
Nominal DC Input Voltage | 12.5 VDC |
No Load battery draw | < 1.2 ADC |
DC Input Voltage operating range | 10.5 – 15.5 VDC |
Under Voltage Alarm | 11.2 VDC |
Under Voltage Shutdown | 10.5 VDC |
Under Voltage Recovery | 11.8 VDC |
Over Voltage Shutdown | 15.5 VDC |
USB | 5V, 2.1A |
Safety and Environmental | |
Conformance | All required Australian Standards |
Agency Markings | RCM |
Operating Temperature | 0°C to 40°C |
Storage Temperature | -20°C to 60°C |
Relative Humidity | 5-90% noncondensing |
Weights and Dimensions | |
Weight | 2.9Kg |
Dimensions (W x L x H) | 177 x 325 x 90mm |
Warranty | 5 Years |
